Core Component for Many Systems

Our company started in Shenzhen in 2004 and moved to Kunshan in 2014. Now we have a mature operation. Our water cooled screw compressor is the core part of many chiller systems. How big is our factory? We have 3,000 square meters. We have 20 workers plus some support staff, about 35 people in total. We follow a simple and practical design principle. So our compressor is easy to operate and easy to maintain. You do not need to hire an expensive engineer for maintenance. Can we provide samples before mass production? We cannot provide samples. But we communicate with you fully to confirm everything, then go directly into production. Compressors are precision equipment. Sample costs are very high. We prefer to save that money and use it for better parts. We use imported semi-hermetic screw compressors with a 5:6 tooth ratio. This is one of the most advanced designs today.

Complete Protection And Safety

Our water cooled screw compressor comes in models from ATX-100WS to ATX-855WS. Cooling capacity from 100kW to 855kW. Input power from 22kW to 180kW. Max running current from 38A to 307A. The energy control range is all 100-75-50-25-0 five-step. Power supply is 3N-50HZ-380V. R22 refrigerant charge from 17kg to 143kg. The evaporator is shell-and-tube. Chilled water flow from 17.2m³/h to 147.1m³/h. The condenser is also shell-and-tube. Cooling water flow from 22.4m³/h to 191.2m³/h. Protection devices include high/low pressure switches, freeze protection, fusible plug, overload protection, coil overheat protection, temperature auto switch, and reverse phase protector. These devices make your equipment very safe to run. Do we meet environmental regulations? Yes, we do. Our factory emissions and noise all meet local requirements.

Full Service And Flexible Payment

This water cooled screw compressor can be sold as a separate unit or as part of our complete chiller system. Many equipment manufacturers buy our compressor to build their own systems. We provide full pre-sales, in-sales, and after-sales service. Pre-sales: we help you choose the right model. In-sales: we provide installation guidance and operation training. After-sales: we offer free warranty and lifetime maintenance. For repeat orders, delivery time can be shorter if the configuration is the same. But if you want custom colors or voltages, it takes about the same time as the first order. Because custom motors take time to make. We accept USD and EUR. Standard payment is 50% deposit and 50% before shipment. Large orders get discounts. Want to buy one unit to try? Minimum order quantity is just one. We look forward to working with you.

Parameter	Unit	ATX-100WS	ATX-130WS	ATX-170WS	ATX-190WS	ATX-255WS	ATX-300WS	ATX-330WS	ATX-400WS	ATX-490WS	ATX-630WS	ATX-770WS	ATX-855WS
Cooling capacity	Kcal/h	86000	111800	146200	163400	219300	258000	283800	344000	421400	541800	662200	735300
Cooling capacity	KW	100	130	170	190	255	300	330	400	490	630	770	855
Input power	KW	22	30	36	45	56	61	70	85	114	132	167	180
Max running current	A	38	51	61	76	95	103	119	145	170	225	285	307
Energy control range	%	100-75-50-25-0	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same
Power supply	-	3N-50HZ-380V	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same
R22 refrigerant charge	KG	17	22	28	35	42.5	50	55	67	82	105	128	143
R22 control method	-	Thermal expansion valve ext. equal.	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same
Compressor type	-	Semi-hermetic screw	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same
Compressor power	KW	22	30	36	45	56	61	70	85	114	132	167	180
Evaporator type	-	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube
Chilled water flow	M³/h	17.2	22.4	29.3	36.6	43.9	51.6	56.8	68.8	84.3	108.4	132.4	147.1
Evaporator water resistance	Kpa	33	33	38	42	45	42	42	45	40	44	44	44
Evaporator pipe size	DN	65	65	65	80	80	100	100	100	125	150	150	150
Condenser type	-	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube	Shell and tube
Cooling water flow	M³/h	22.4	29.2	35.2	46.1	57.1	67.1	74	89.4	110	141	172.2	191.2
Condenser water resistance	Kpa	38	43	43	48	48	45	45	48	45	49	49	49
Condenser pipe size	DN	65	65	65	80	80	100	100	100	125	150	150	150
Protection devices	-	HP/LP switch, freeze stat, fusible plug, overload, coil overheat, temp auto switch, reverse protector	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same	Same
Length	MM	2500	2600	2650	2800	3000	3000	3100	3200	3606	3900	4200	4400
Width	MM	750	750	750	750	750	900	900	900	1280	1320	1320	1320
Height	MM	1800	1800	1800	1800	1800	1900	1900	1900	1600	1650	1650	1650
Unit weight	KG	800	880	1000	1000	1500	1800	1900	2000	2490	3200	3400	3600
Running weight	KG	900	1110	1200	1200	1650	1960	2050	2180	2650	3500	3700	3900
